Delta DVP32EH00T3 | DELTA | EH3 Series PLC

Description

The new generation DVP-EH3 PLC is the high-end model in the Delta DVP-E series. It provides greater program capacity and data registers for more demanding and complex applications.

• Manufacturer : DELTA
• Product No. : DVP32EH00T3-L
• Product Type : Programmable Logic Controller
• Power Supply Voltage : 100 ~ 240VAC (-15% ~ 10%); 50/60Hz ± 5%
• Fuse Capacity: 2A/250VAC
• Power consumption : 80VA maximum
• DC24V current output : 500mA
• Power Supply Protection : DC24V output short circuit protection
• Voltage Withstand : 1,500VAC (Primary-secondary), 1,500VAC (Primary-PE), 500VAC (Secondary-PE)
• Insulation Resistance : > 5MO at 500VDC (between all I/O points and ground)
• Vibration / Shock Resistance : IEC61131-2, IEC 68-2-6 (TEST Fc)/ IEC61131-2 & IEC 68-2-27 (TEST Ea)
• Dimensions (L x W x H) : 14.3cm x 8.2cm x 9cm
• Weight : 0.5 Kg
